SMT Parameters:
| Technology |
Circuit |
PCB/Flex/Metal PCB/Rigid-Flex |
Parameter |
Assembly Side |
Single/Double |
| Process |
SMT |
Min Size |
10mm * 10mm |
| THT |
Max Size |
410mm * 350mm |
| Punch |
Thickness |
0.38mm ~ 6.00mm |
| In-circuit Test Function Test |
Min Chip |
0201 chip |
| Glue,Burn-in Conformal Coating |
Fine-pitch |
0.20mm |
| BGA Re-work |
BGA ball size |
0.28mm |
Technology Involved:
| H 高 |
◆SMT+ICT+THT+FT ◆SMT+ICT+THT+Harness+Assembly+FT |
◆SMT machine(for printing,pick place,reflow soldering) ◆THT machine(for wave soldering) ◆Terminal machine... |
◆AOI ◆X-RAY ◆injection molding machine ◆AI(Automatic Inserting machine)... |
| M 中 |
◆SMT+ICT ◆THT+FT ◆SMT+THT ◆THT+Harness+FT ◆Assembly+FT |
◆ Genera SMD+DIP ◆ DIP parts+ Harness ◆SMD+DIP+Harness without injection molding |
◆≤0201 SMD ◆BGA,LGA,FBGA,LCC+LGA ◆Harness+injection molding ◆Conformal coating |
| S 低 |
◆纯SMT(Only SMT) ◆纯THT(Only THT) ◆纯线束(Only Harness) ◆纯组装(Only Assembly) |
◆代工代料 Material+ Assembly |
◆设计+代工代料 Design+Meterial+Assembly |
| |
low |
higher |
highest |
Special Technology Involved
◆ IC Programming
◆ BGA rework
◆ Chip on Board/COB
◆ Eutectic soldering
◆ Auto-Gluing
◆ Conformal Coating
Assemly Flow Chart:
Suntek Group is a professional contract factory on one-stop solution for PCB/FPC assembly,Cable assembly,Mix technoloty assembly and Box-build assembly.
Suntek Electronics Co.,Ltd,as a major facility,located in Hunan province,China;
BLSuntek Electronics Co.,Ltd,as the new facility,located in Kandal province,Cambodia.
With ISO9001:2015,ISO13485:2016,IATF 16949:2016 and UL E476377 certified.We deliver qualified products with competitive price to clients all over the world.We have the advanced manufacturing equipments,proficient technology,professional engineer team,purchasing team,quality team and management team to guarantee the high quality products and on time delivery.
Our products are widely used in industrial control,auto,telecommunications,medical equipment,consumer electronics and etc.
core is "Quality wins Market, Ideas create the Future".
FAQ:
Q1: What files do you use in PCB fabrication?
A1: Gerber,BOM,Drawings.
Q2: How do you make sure the quality?
A2: Our Product is all 100% E-tested .PCB Assembly are with 100% AOI,ICT,FT and Visual checking,100% X-ray for BGA.
Q3: Can we visit your company?
A3: Of course,Welcome to visit our company, Suntek located in Xingsha Industrial Park, Changsha,Hunan province, China.
Q4: What is the lead time?
A4: It takes 3-5 working days for sample, 7-10 working days for batch production based on files and quantity. It takes 15-20 working days for PCB assembly.
Q5: Will you keep our information and files secret?
A5: Sure,It is our basic principle to keep business secrets to protect our customers' designs.NDA can be signed at any time.
Q6. How to work with you?
A6: -Email and send us the PCB layout file, BOM list
- We will provide reply confirmation within 12 hours and reply to the offer within 3-5 days.
- Waiting for your company to confirm the price, order and payment terms.
- We will proceed the order.
